Kailh Red Bean Pudding Box Switch Set
Linear Typing Feel
The Kailh Red Bean Pudding Switch is a box switch with a comfortable linear typing feel. This switch is built with a red stem, a translucent cover, and a POM material base. Its whole appearance reminds us of a pudding with a touch of red bean as a pop of color, one of our favorite refreshing desserts.
POM Material Stem And Base
The Red Bean switch is equipped with a stem and base made of self-lubricating POM material and delivers a ultra-smooth feel.
Short Spring. Stronger Rebound
Crafted with a 13mm short spring, this box switch has more than 35 grams of return force to offer a strong sense of feedback.
90% Light Transmittance
The switch has a light guide post within the switch housing to let more RGB light shine through and can reach 90% light transmittance.
90% Light Transmittance
The switch has a light guide post within the switch housing to let more RGB light shine through and can reach 90% light transmittance.
Dustproof & Waterproof “Box” Design
Its box design has dustproof and waterproof features, increasing the switch’s lifespan and longevity.
Product Structure
Technical Data
Red Bean Pudding Switch
| Type | Linear |
|---|---|
| Operation Force | 45±10 gf |
| Pre-travel | 1.8±0.4 mm |
| Return Force | ≥35 gf |
| Total Travel | 3.6±0.3 mm |
| Sound Level | Low |
| Operation Life | Up to 80M cycles |
| Suitable For | Gaming/office |
Product Spec
| Product Name | Kailh Red Bean Pudding Switch |
|---|---|
| Stem | POM |
| Top Housing | PC |
| Bottom Housing | POM |
| Contact | Composite gold |
| Spring | Spring steel |
| Protecting Cover | Nylon |
| Slider | POM |
| Light Guide Post | PC |
| Pins | 5-Pin |
| Factory Pre-lubed | No |
| SMD LED Support | Yes |
